Terminales / Empalmadores de conexión prensados
Terminales bimetalicos, estancos longitudinalmente
•
para cables de aluminio conforme a DIN 48201 parte 1ª, cables de aluminio conforme a DIN EN 50182
•
material: AL (aluminio) 99,5% DIN 40501, E-CU DIN 40500
•
superficie: pulida
•
marcado a presión
•
incluye grasa de contacto
N°art.
kg/100
UdE
293300
2,600
50
293302
2,500
50
293304
2,900
50
DC rm/sm
se M IN d2 d1 v1 v2
l
B
25
35 8 12 10,5 6,8 4 2 61,0 23,0
10 12 10,5 6,8 4 2 61,0 23,0
12 12 13,0 6,8 4 2 61,0 23,0
293306
3,200
50
293308
3,500
50
35
50 10 14 10,5 8,0 5 2 71,0 23,0
12 14 13,0 8,0 5 2 71,0 23,0
293310
3,400
50
293312
4,100
50
50
70 10 16 10,5 9,8 5 2 72,0 25,0
12 16 13,0 9,8 5 2 72,0 25,0
293314
6,100
50
293316
5,500
50
70
95 10 18 10,5 11,2 6 3 82,0 26,0
12 18 13,0 11,2 6 3 82,0 26,0
293318
8,200
25
293320
8,500
25
95
120 12 22 13,0 13,2 6 3 85,0 30,0
16 22 17,0 13,2 6 3 85,0 30,0
293322
8,500
25
293324
8,700
25
120
150 12 22 13,0 14,7 6 3 87,0 30,0
16 22 17,0 14,7 6 3 87,0 30,0
293326
11,000
25
293328
11,200
25
150
185 12 25 13,0 16,3 6 3 104,0 36,0
16 25 17,0 16,3 6 3 104,0 36,0
293330
14,100
10
293332
14,300
10
185
240 12 28 13,0 18,3 6 3 105,0 36,0
16 28 17,0 18,3 6 3 105,0 36,0
293334
18,000
5
293336
29,000
5
240
300 12 32 13,0 21,0 8 3 120,0 36,0
20 32 17,0 21,0 8 3 120,0 36,0
293338
35,000
5
300
300 12 34 13,0 23,3 8 3 120,0 38,0
Empalmadores bimetalicos
•
para cables de aluminio conforme a DIN 48201 parte 1ª, cables de aluminio conforme a DIN EN 50182
•
material: AL (aluminio) 99,5% DIN 40501, E-CU DIN 40500
•
superficie: pulida
•
marcado a presión
•
incluye grasa de contacto
N°art.
kg/100
UdE
293960
1,600
1
DC rm/sm
se d1 d4 LT
l ØBo. ØC.cu IN Al
25
35 6,8 12,0 58 20,0 6 6,3 12
293962
2,800
1
35
35 8,0 14,0 71 22,0 7 7,5 14
293964
3,800
1
50
50 10,0 16,0 74 25,0 8 9,0 16
293966
5,400
1
70
70 11,5 18,5 87 30,0 10 10,0 18
293968
10,600
1
95
120 13,2 23,0 91 33,0 12 12,5 22
293970
9,000
1
120
150 15,0 23,0 97 38,0 12 14,0 22
293972
10,900
1
150
185 16,5 25,5 108 38,0 12 15,8 25
293974
15,700
1
185
240 18,5 28,5 116 44,0 14 17,5 28
293976
17,000
1
240
300 21,5 32,5 128 44,0 16 20,3 32
293978
23,200
1
300
- 23,5 34,5 131 46,0 18 22,5 34
